The Fiamma Handle Security 46 (03513A01-) is a dual-purpose locking door handle that adds both security and convenience to your caravan or motorhome.
When folded across the door, it acts as a solid locking bar to help prevent forced entry. When opened out, it functions as a sturdy grab handle for safe access to your vehicle.

OEM Part Number: 03513A01-
Compatible With: Caravan and motorhome main doors
Material: Anodised aluminium
Colour / Finish: White powder-coated aluminium
Included: Handle assembly, lock barrel with keys, mounting brackets, backing plates, fixing hardware

Featrues:

• 2-in-1 design: Works as both a grab handle and locking door security bar

• Longer 46 cm version: Ideal for taller caravan or motorhome doors

• Sturdy construction: 30 mm anodised aluminium tube for maximum strength

• Weather-resistant: Powder-coated white finish resists corrosion and UV damage

• Lockable: Integrated barrel lock with two keys for peace of mind

• Easy installation: Includes all required fixings, plates, and hardware

• Comfortable grip: Ergonomic tube diameter for secure handhold

Specifications:

• otal Height (Handle Length): 46 cm (460 mm)

• Handle Tube Diameter: 30 mm

• Overall Width (open grab-handle position): 33.5 cm (335 mm)

• Wall Projection (when folded and locked): 65 mm

• Bracket Centre-to-Centre Distance: 355 mm (vertically between brackets)

• Bracket Bolt Hole Spacing (each bracket): 50 mm

• Total Bolt-to-Bolt Distance (top bracket to bottom bracket): 415 mm

Frequently Asked Questions

Q: What is the difference between the Handle Security 31 and 46?
The Handle Security 46 is 15 cm longer than the 31, giving extra reach and leverage — perfect for taller or wider doors on motorhomes or larger caravans.

Q: What does it do?
It acts as both a security bar (when folded across the door and locked) and a grab handle (when opened for use).

Q: Does it include everything needed for installation?
Yes. It includes the handle, lock barrel, keys, mounting brackets, backing plates, and all necessary fixings.

Q: How does it lock?
The handle folds across the door and locks in place using the built-in keyed barrel lock. Two keys are supplied.

Q: Can it be mounted on either side of the door?
Yes. It’s reversible for left- or right-hand door openings.

Q: What material is it made from?
Strong, lightweight anodised aluminium, with a durable white powder-coated finish.
