The 91632C LED Rear End Outline Marker Lamp is a high-visibility rear marker designed to clearly define the rear outer edges of caravans, trailers, motorhomes, and commercial vehicles. Featuring a red LED lens with a chrome base, this lamp provides a clean, modern finish while meeting on-road compliance requirements.

Built with long-life LED technology and a fully sealed housing, this marker lamp is designed to withstand harsh road and weather conditions. Its wide 9–33V DC operating range makes it suitable for both 12V and 24V systems, making it ideal for caravans, RVs, and heavy vehicles.

Features:

• Rear end outline / clearance marker lamp

• Red LED lens with chrome base

• Wide voltage operation: 9–33V DC (12V & 24V compatible)

• Ultra-low power consumption

• Long-life LEDs rated up to 100,000 hours

• High visibility output

• Fully sealed for external vehicle use

• Suitable for caravans, trailers, motorhomes, trucks, and commercial vehicles

Specifications:

• amp Type: Rear end outline marker lamp

• Part Number: 91632C

• Lens Colour: Red

• Base Colour: Chrome

• Voltage Range: 9–33V DC

• Current Draw: 0.02 A

• LED Life Rating: Up to 100,000 hours

• IP Rating: IP66 & IP68 (dustproof and waterproof)

• Candela Rating: 46 cd

• Overall Size: 74 mm × 38 mm

• ADR Compliance:

  • Vertical: ADR 49/00 – 30945

  • Horizontal: ADR 49/00 – 30946

• Comprises: 91630; 91689
