The Sphere 175 Litre Upright DC Compressor Fridge/Freezer is a reliable mid-size cooling solution designed specifically for caravans, motorhomes,  operating on 12V DC power. With a smart upright layout and generous internal storage, it delivers dependable fridge and freezer performance while fitting neatly into a standard built-in cavity.

This model offers a well-balanced combination of a 137 L fridge compartment and a 38 L freezer, giving you a total capacity of 175 litres —ideal for extended off-grid trips. Powered by an efficient DC compressor with Sphere’s Cold Air Bank efficiency system, it provides excellent cooling performance with low power consumption.

User-friendly controls include a digital display with adjustable temperature settings, Night mode for quiet operation, and Boost mode for faster pull-down when loading fresh supplies. A built-in three-stage battery protection system helps protect your battery by automatically shutting the fridge down if voltage drops too low.

Designed for Australian conditions, the fridge features a tropical climate rating (T/ST), internal fan for even cooling, shockproof construction for off-road use, and a reversible door for flexible installation.

Features:

• 175 L total capacity including 38 L freezer and 137 L fridge

• 12 V DC compressor system with Cold Air Bank efficiency technology

• Independent temperature control for fridge and freezer compartments

• Fridge temperature range: 0 °C to +10 °C

• Freezer temperature range: Down to -20 °C

• Night quiet mode for reduced noise while sleeping

• Boost mode for faster cooling when required

• Three-stage battery protection to prevent excessive battery drain

• Internal circulation fan for even cabinet temperature

• LED interior lighting for clear visibility

• Adjustable wire shelves, crisper drawer, and door bins

• Bottle holder to keep drinks secure during travel

• Shockproof design suitable for off-road conditions

• Flush-fitting door for clean built-in installation

• Reversible door hinge (supplied right-hand, reversible)

• 2-year warranty

Specifications:

• Brand: Sphere

• Model / SKU: 700-22108

• Model Name: UCF175

• Overall Capacity: 175 L

• Fridge Capacity: 137 L

• Freezer Capacity: 38 L

• Voltage: 12 V DC

• Average Current Draw:

  • ~2.7 A over 24 h (Boost mode)

  • ~2.08 A over 24 h (Night mode)

• Climate Class: T / ST

• Ambient Operating Temperature: +16 °C to +43 °C

• Temperature Range (Fridge): 0 °C to +10 °C

• Temperature Range (Freezer): Down to -20 °C

• Door Hinge: Right-hand (reversible)

• Overall Dimensions (mm): 523 (W) × 1245 (H) × 563 (D)

• Cut-Out Dimensions (mm): 527 (W) × 1248 (H) × 596 (D)

• Net Weight: 35.5 kg

Frequently Asked Questions (FAQ)

Q: Is this fridge suitable for off-grid use?
Yes ,  it runs on 12V DC only and features low average current draw plus battery protection, making it ideal for off-grid caravans and motorhomes.

Q: Does this fridge run on 240V power?
No , this model is 12V DC only.

Q: Is it noisy when running?
No ,  the fridge includes a Night quiet mode, which reduces noise output for comfortable sleeping conditions.

Q: Can the door be reversed?
Yes ,  the fridge is supplied with a right-hand hinge but the door can be reversed during installation.

Q: What size cavity do I need for installation?
You’ll need a cut-out of 527 mm wide × 1248 mm high × 596 mm deep, with proper ventilation as per installation guidelines.
