Trail-A-Mate Hydraulic Jockey Wheel & Jack Kit 1000kg

Replace your standard jockey wheel and give you a powerful hydraulic jack in one compact setup, the Trail-A-Mate Hydraulic Jockey Wheel & Jack Kit is the ultimate lifting and manoeuvring solution for caravans, trailers, horse floats, food vans and motorhomes. Whether you’re hitching up, levelling, moving your van into position or changing over to jack mode, this clever unit helps take the hard work out of lifting and handling your setup.

With a simple change from wheel to base plate, the Trail-A-Mate converts from a jockey wheel into a hydraulic jack without needing to remove it from your A-frame. It suits standard 50mm clamps, offers a 1000kg safe working load, and is suitable for caravans and trailers up to 2900kg ATM.

Features:

Dual function jockey wheel and hydraulic jack

1000kg safe working load

Suitable for caravans and trailers up to 2900kg ATM

Converts from wheel to jack with included base plate

Fits standard 50mm jockey wheel clamps

Hydraulic lift for easier operation

Four clamp positions on 500mm outer shaft

Built-in safety lock

Suits standard height and off-road models

Complies with AS/NZS 2693:2007

Specifications:

Working Load Limit: 1000kg

Suitable ATM: Up to 2900kg

Minimum Height: Approx. 145mm

Maximum Height: Approx. 780mm

Lifting Range: Approx. 380mm

Shaft Diameter: 50mm

Outer Shaft Length: 500mm

Clamp Positions: 4

Clamp Suitability: Standard 50mm jockey wheel clamps

Standard Compliance: AS/NZS 2693:2007

What:s Included:

Hydraulic jack / jockey wheel unit

Wheel assembly

Base plate with pin

Lifting clamp

Jacking brackets

Jacking handle

Extendable wheel brace

Full instructions

Swafety Inscturctions:

Use on level, firm ground wherever possible

Chock caravan or trailer wheels before lifting

Do not remain inside a caravan or trailer supported by a jack

Do not place any part of your body under a caravan or trailer supported by a jack

Keep the caravan or trailer attached to the towing vehicle when jacking

FAQ

Q: Does it fit standard jockey wheel clamps?
Yes, it is designed to suit standard 50mm jockey wheel clamps

Q: What are the clamp height positions with the wheel fitted?
With the wheel fitted, the measurement from the bottom of the wheel to the clamp notches is approximately:
280mm to the first notch
370mm to the second notch
460mm to the third notch
550mm to the top notch

Q: How much extra lift does the hydraulic jack provide?
Once positioned in the clamp, the hydraulic jack can provide an additional lift of approximately 380mm

Q: What is the working load limit?
The Trail-A-Mate has a 1000kg working load limit.

Q: What size caravan or trailer is it suitable for?
It is suitable for caravans, trailers and similar vehicles with an ATM up to 2900kg.
